Cisco SFP Transceiver Module 1.25G BIDI WDM Single Mode 20km 1310nm 1550nm DDM

  • 1
  • 2
  • 3

Brand Name : Olycom

Model Number : OSBL1G20D-35/53

Certification : CE RoHS FCC ISO9001

Place of Origin : Guangdong, China

MOQ : 1 pc

Price : Negotiable

Payment Terms : T/T, PayPal

Supply Ability : 5000pcs/month

Delivery Time : 3~5 working days

Packaging Details : 1pc in a box

Product name : 1.25g bidi sfp optical module

Wavelength : 1310/1550nm

Distance : 20KM

Type : Single mode single fiber bi-directional transmission

Contact Now

1.25G Cisco Sfp Transceiver Module 20KM

Features of BIDI SFP Transceiver
  • Up to 1.25Gb/s Data Links
  • Hot-Pluggable
  • Single LC connector
  • Up to 20 km on 9/125μm SMF
  • 1310nm FP laser transmitter
  • 1550nm PIN photo-detector
  • Single +3.3V Power Supply
  • Monitoring Interface Compliant with SFF-8472
  • Maximum Power <1W
  • Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available
  • RoHS compliant and Lead Free

Introduction of Cisco SFP Module

  • OLYCOM’s OSBL1G20D-35 Transceivers are a high performance, cost effective module which have a single LC optics interface.
  • They are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) and Digital diagnostics functions are available via the 2-wire serial bus specified in SFF-8472.
  • The receiver section uses a PIN receiver and the transmitter uses a 1310 nm FP laser, up to 14dB link budge ensure this module 1000Base-LX Ethernet 20km application.

Absolute Maximum Ratings

Parameter Symbol Min Max Unit
Supply Voltage Vcc -0.5 4.5 V
Storage Temperature Ts -40 +85 °C
Operating Humidity - 5 85 %

Recommended Operating Conditions

Parameter Symbol Min Typical Max Unit
Operating Case Temperature Standard Tc 0 +70 °C
Extended -20 +80 °C
Industrial -40 +85 °C
Power Supply Voltage Vcc 3.135 3.30 3.465 V
Power Supply Current Icc 300 mA
Data Rate 0.1 1.25 Gbps

Optical and Electrical Characteristics

Parameter Symbol Min Typical Max Unit Notes
Transmitter
Centre Wavelength λc 1260 1310 1360 nm
Spectral Width(RMS) Δλ 3 nm
Side-Mode Suppression Ratio SMSR - - - dB
Average Output Power Pout -9 0 dBm 1
Extinction Ratio ER 9.0 dB
Data Input Swing Differential VIN 180 1200 mV 2
Input Differential Impedance ZIN 90 100 110 Ω
TX Disable Disable 2.0 Vcc V
Enable 0 0.8 V
TX Fault Fault 2.0 Vcc V
Normal 0 0.8 V
Receiver
Centre Wavelength λc 1530 1550 1570 nm
Receiver Sensitivity -23 dBm 3
Receiver Overload -1 dBm 3
LOS De-Assert LOSD -24 dBm
LOS Assert LOSA -38 dBm
LOS Hysteresis 0.5 4 dB
Data Output Swing Differential Vout 600 800 1000 mV 4
LOS High 2.0 Vcc V
Low 0.8 V

Ordering information

Part Number Product Description
OSBL1G20D-35 1310T/1550R, 1.25Gbps, LC, 20km, 0°C~+70°C, with DDM
OSBL1G20DI-35 1310T/1550R, 1.25Gbps, LC, 20km, -40°C~+75°C, with DDM
